Range:
Pipe      1/4" to 4" I.D.
Tubing   5/8" to 4 1/2" O.D.

Dimensions:
19"L X 10"W X 19"H

Drive Type:
Gear Driven Rollers

Cutter Wheel:
Heat-treated, high-speed tool-steel

Motor:
2-3/4 HP Universal AC/DC 50-60 Hz. 115V. Standard Supply.
3 HP Universal AC/DC. 50-60 Hz. 230V motor optional

Shipping Weight:
Collins E-Z Cutter Model A 121 lbs.


• Fast, high volume production cutter makes quick work of 1/4" - 4" pipe and 5/8" to 4 1/2" tubing.
• Built to withstand everyday knocks and abuses yet light enough to set up anywhere.
• Universal AC/DC motor provides a full 2-3/4 HP for meeting all-day production needs.
• Gear-driven rollers turn the work for true perpendicular cutting.
• Ball-bearing assembled cutter wheel revolves freely for even wear.
• High-speed tool-steel cutter wheels assure thousands of clean cuts with no external burr-so clean that no further finishing is needed before applying fittings.
• Foot switch provides operator safety while freeing both hands for high-volume production demands.
• Sold as is

Turn your Collins EZ Cutter^® electric pipe cutter into a complete production system with these time-saving accessories.

For bench mounting:

• Stationary Support #00036 for Collins EZ Cutter mounts your 1 1/4" support pipe to the work bench surface.
• Roller Bearing Support #00069 for Collins EZ Cutter slides onto the support pipe and provides easy travel and rotation of work.

For floor mounting:

• Collins EZ Cutter^® electric pipe cutter Stand #00037 bolts to the floor for stationary support.
• Pipe Support Fitting #00071 for Collins EZ Cutter (with 1" pipe legs making a sturdy work horse) mounts onto 1 1/4" pipe also using the Roller Bearing Support on support pipe.
• Pipe Jack with Ball-Bearing Transport Head #00101 for Collins EZ Cutter replaces system of support pipe and fittings, providing a handy alternative for supporting the work.

Description	lbs.	No.	$ Price	Buy Now
RECONDITIONED Collins E-Z Cutter, Model A with one cutting wheel and NEW Footswitch    *One available	120.00	00032	SOLD

^{Rothenberger's Pneumatic Mini-Collins weighs only 27 pounds and is the most portable air powered threader available!}

• ^{For complete safety in hazardous environments such as petroleum and chemical plants, mines or tunnels}
• ^{Reversible, non-sparking air motor develops 500 foot pounds of torque in either direction}
• ^{Cannot be damaged by overload, even when operated to point of stall}
• Puts power back into power threading-threads up to 2" pipe or conduit, 1" bolt or rod in seconds!
• Lightweight and engineered to go anywhere-requires only 1 3/4" clearance for working in trenches, overhead, and in tight quarters where only hand tools could be used before.
• Convenient maintenance-built-in fill plug eliminates disassembly of gearbox for oiling
• Has the muscle to make any turning job easy-tightens nuts, drives cable pullers, turns hoists and jacks, opens and closes valves, or drives up to 6" geared threaders

Description	lbs.	No.	$ Price	Buy Now
USED (Demo) Pneumatic Mini-Collins	29.00	00078	$1,999.90	Buy now

USED Rothenberger Collins THRED-O-MATIC 44A

Standard Unit with Three Dual (1/2" - 3/4") (2.1/2" - 3"), (3.1/2" - 4") and one Quad (1" - 2") Snap-O-Matic Die Heads and NPT High Speed Dies. Includes: and 1/2" - 2" Cone Reamer Assembly

Range: (Standard Unit)

• Pipe or conduit 1/2" - 4"
• Bolt or rod 19 to 76mm, 3/4" to 3"

Dimensions

• Length 60", Width 30", Height 44 1/2", height to center line of spindle 35 1/2", carriage travel 13"

Spindle Speed

• While threading 1/2" to 1" - 48 RPM
• While threading 1 1/4" to 2" - 26 RPM
• While threading 2 1/2" to 3" - 16 RPM
• While threading 3 1/2" to 4" - 12 RPM

Description	lbs.	No.	$ Price	Buy Now
Rothenberger Collins 44A	1,350.00	00039	$OLD

Includes: Dies

Description	lbs.	No.	$ Price	Buy Now
USED Ridgid 36620 Receding Geared Threader	95.00	36620	$1,499.90

To order from CMS Industrial Equipment Company today, simply shop online, or fax your order, The staff at our US offices can also help you make the best choice in Rothenberger tools for all of your pipe cutting needs.
